• Country
• Japan

• Manufacturer / Brand
• JVC - Victor Company of Japan, Ltd.; Tokyo

• Year
• 1949 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 216119

• Number of Tubes
• 7

• Valves / Tubes
• UZ-6D6 or 6D6 UZ-6D6 or 6D6 6SA7GT 6SQ7GT 6E5 42 80K

• Main principle
• Superhet with RF-stage; ZF/IF 455 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 85-100 Volt

• Loudspeaker
• Magnetic loudspeaker (reed) generic.

• Power out
• 2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Victor R-720B - JVC - Victor Company of Japan,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 325 x 490 x 245 mm / 12.8 x 19.3 x 9.6 inch

• Notes
• Victor 2 Band Radio R-720B; BC: 535 - 1.605 Kc, SW: 6 - 10 MHz.

• Author
• Model page created by Masanori Hoki. See "Data change" for further contributors.
