• Country
• Japan

• Manufacturer / Brand
• JVC - Victor Company of Japan, Ltd.; Tokyo

• Year
• 1979 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 315637

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Alternating Current supply (AC) / 110/120/220/240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Stereo Cassette Deck KD-35B - JVC - Victor Company of Japan,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 390 x 151 x 328 mm / 15.4 x 5.9 x 12.9 inch

• Notes

• Type: 2-head, single compact cassette deck
  Track System: 4-track, 2-channel stereo
  Tape Speed: 4.8 cm/s
  Heads: 1 x record/playback (SEN-ALLOY), 1 x erase (double gap Ferrite)
  Motor: electronic governor DC
  Tape Type: type I, FeCr, CrO2
  Noise Reduction: B
  Frequency Response: 20Hz to 16kHz  (Cr02 tape), 20Hz to 15kHz  (Normal tape)
  Signal to Noise Ratio: 56dB  without Dolby NR, improved by 5dB at 1kHz and by 10dB above 5kHz with Dolby NR ON
  Wow and Flutter: 0.06% WRMS
  Crosstalk: 56dB at 1kHz
  Channel separation: 35dB at 1kHz
  Total Harmonic Distortion: 1.3%
  Input: 80mV (line), 0.2mV (mic)
  Output: 0.41V (line)

• Net weight (2.2 lb = 1 kg)
• 7.2 kg / 15 lb 13.7 oz (15.859 lb)

• Author
• Model page created by Bartosz Szwed. See "Data change" for further contributors.
