Stereo Radio Cassette Recorder RC-M90JW Boombox

JVC - Victor Company of Japan, Ltd.; Tokyo

Data
Forum
Pictures
Collections

  • Year
  • 1985 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 146201

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, more than 2 SW bands plus FM or UHF.
  • Details
  • Cassette-Recorder or -Player; Remote Control (with wire or wireless)
  • Power type and voltage
  • Line / Batteries (any type) / 120; 220; 240/ 12; 10 x 1,5 Volt
  • Loudspeaker
  • 4 Loudspeakers
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Stereo Radio Cassette Recorder RC-M90JW Boombox - JVC - Victor Company of Japan,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 668 x 350 x 177 mm / 26.3 x 13.8 x 7 inch
  • Notes
  • JVC RC-M90JW Stereo Radio Cassette Recorder;
    Boombox - Ghettoblaster, Big Power 2 x ~20 W, 8-band tuner: AM-MW, FM up to 108 MHz, six SW bands, fine tuning,
    tape counter, 2 motor full logic control, response up to 30 - 17.000 Hz (metal), normal/CrO²/metal tape bias/EQ, "Multi Music Scanner", rec./playback timer, Dolby NR or Super ANRS,
    two built in mics, left & right rec. level control, mixing mic. level control, 2 VU /batt./tuning meters, bass-, treble & balance control, loudness switch, mono/stereo, two telescopic antennas, ext. 300 ohm FM ant in, beat cut selector, jacks for headphones and 2 x mics., 2 x mixing mics. in, ext. speakers (6 - 16 ohm), RCA phono in with earth screw terminal switchable to line in, front DIN terminal for an optional cable remote control, RCA line out, 12 VDC in, 120 VAC pre-set, 61 W mains power consumption, made in Japan,
    compare most similar JVC or Victor RC-M90's versions but with different coverage and power supply.
  • Net weight (2.2 lb = 1 kg)
  • 10 kg / 22 lb 0.4 oz (22.026 lb)
  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
