• Country
• Japan

• Manufacturer / Brand
• JVC - Victor Company of Japan, Ltd.; Tokyo

• Year
• 1978 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 242806

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC)

• Loudspeaker
• - For headphones or amp.

• Material
• Various materials

• from Radiomuseum.org
• Model: Stereo Tuner T-E55L - JVC - Victor Company of Japan,

• Shape
• Rack

• Notes

• Gamma FM da 87,5 a 108 MHz, Gamma AM da 522 a 1611 kHz, Gamma OL da 153 a 360 kHz.

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Fabio Masetti. See "Data change" for further contributors.

• Other Models

• Here you find 994 models, 877 with images and 144 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from JVC - Victor Company of Japan, Ltd.; Tokyo
