Nejva {Нейва} [Neywa] 304

• Country
• Soviet Union

• Manufacturer / Brand
• Kamensk-Uralsk Radio Works

• Year
• 1987/1988

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 85443

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 11

• Semiconductors
• КТ315 КТ315 КТ315 КТ315 КТ315 КТ315 КТ361 КТ315 КТ315 КТ315 КТ315

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Tuned circuits
• 4 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 0.15 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Nejva {Нейва} [Neywa] 304 - Kamensk-Uralsk Radio Works

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 145 x 80 x 39 mm / 5.7 x 3.1 x 1.5 inch

• Notes
• External aerial and earphones sockets.

• Net weight (2.2 lb = 1 kg)
• 0.4 kg / 0 lb 14.1 oz (0.881 lb)

• Price in first year of sale
• 31.00 RUR

• Source of data
• - - Data from my own collection

• Author
• Model page created by Zenonas Langaitis. See "Data change" for further contributors.

• Other Models

• Here you find 21 models, 20 with images and 13 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
