• Country
• Soviet Union

• Manufacturer / Brand
• Kamensk-Uralsk Radio Works

• Year
• 1964 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 352927

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• ГТ309 ГТ309 ГТ309 ГТ108 ГТ108 ГТ108 ГТ108

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / 6F22: 1 x 9 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch

• Power out
• 0.06 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Нейва Neiva [old] - Kamensk-Uralsk Radio Works

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 115 x 72 x 35 mm / 4.5 x 2.8 x 1.4 inch

• Net weight (2.2 lb = 1 kg)
• 0.350 kg / 0 lb 12.3 oz (0.771 lb)

• Price in first year of sale
• 33.00 Rubl

• Author
• Model page created by Nikolai Galak. See "Data change" for further contributors.
