Compact-Verstärker VCH 43 BN 230122

Kathrein; Rosenheim

Data
Forum
Pictures
Collections

  • Year
  • 1994 ??
  • Category
  • RF (Radio Frequency-) Amplifier
  • Radiomuseum.org ID
  • 260176

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Radio Frequency Amplification only
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 230 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Compact-Verstärker VCH 43 BN 230122 - Kathrein; Rosenheim
  • Shape
  • Miscellaneous shapes - described under notes.
  • Dimensions (WHD)
  • 205 x 195 x 81 mm / 8.1 x 7.7 x 3.2 inch
  • Notes

  • Antennenverstärker mit 4 Eingängen und 1 Ausgang,

    1. Eingang: 47-68 MHz, 30 dB, Dämpfungssteller,

    2. Eingang: 87,5-108 MHz, 30 dB, Dämpfungssteller, 0,15-10 MHz ohne Verstärkung,

    3. Eingang: 174-230 MHz, 40 dB, Dämpfungssteller,

    4. Eingang: 470-862 MHz, 40 dB, Dämpfungssteller,

  • Net weight (2.2 lb = 1 kg)
  • 2 kg / 4 lb 6.5 oz (4.405 lb)
