• Country
• Germany

• Manufacturer / Brand
• Kathrein; Rosenheim

• Year
• 1994 ??

• Category
• Digital terrestrial, Internet and SAT receiver (also analogue)

• Radiomuseum.org ID
• 259856

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• RF Converter/Adapter (not voltage converter)

• Wave bands
• SAT-IF

• Power type and voltage
• Alternating Current supply (AC) / 230 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: DSR-Umsetzer UWS 10 BN 267601 - Kathrein; Rosenheim

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 248 x 232 x 100 mm / 9.8 x 9.1 x 3.9 inch

• Notes

• Umsetzer für Digitalen Satelliten Rundfunk (DSR) auf 118 MHz,

  fest eingestellt auf Kopernikus LNC-ZF 1175 MHz.

  Den Umsetzer UWS 10 gibt es auch in der Option:
  -  UWS 10  BN 267602 für TV-Sat 1226 MHz,
  -  UWS 10  BN 267603 für Kopernikus Duo-Speisesystem, 1500 MHz.

• Net weight (2.2 lb = 1 kg)
• 2.8 kg / 6 lb 2.7 oz (6.167 lb)

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by a member from D. See "Data change" for further contributors.
