• Country
• Germany

• Manufacturer / Brand
• Kathrein; Rosenheim

• Year
• 2004

• Category
• Antenna (Aerial) or Coupler

• Radiomuseum.org ID
• 240788

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Radio Frequency Amplification only

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Powered by external power supply or a main unit. / 5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: DVB-T-Indoor-Antenne aktiv BZD30 - Kathrein; Rosenheim

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 195 x 140 x 18 mm / 7.7 x 5.5 x 0.7 inch

• Notes

• Aktive TV-Zimmerantenne speziell für DVB-T. Versorgungsspannung 5V/30mA über das Antennen-Koaxial-Kabel aus dem DVB-T-Receiver. Graues 4-eckiges flaches Kunststoffgehäuse.

  Empfangsbereiche:                                                                                               174MHz - 230MHz (VHF Band III)                                                                          470MHz - 862MHz (UHF)

• Net weight (2.2 lb = 1 kg)
• 0.5 kg / 1 lb 1.6 oz (1.101 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
