• Country
• Germany

• Manufacturer / Brand
• Kathrein; Rosenheim

• Year
• 1994 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 260326

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 88-260 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Rauschgenerator MNK 20 BN 208252 - Kathrein; Rosenheim

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 160 x 70 x 185 mm / 6.3 x 2.8 x 7.3 inch

• Notes

• Rauschgenerator, 45-2050 MHz,

  Ausgangspegel 90 dBµV,

  schaltbare Dämpfungsschritte 6 / 10 / 20 dB,

  schaltbare 1 KHz Modulation.

• Net weight (2.2 lb = 1 kg)
• 1.1 kg / 2 lb 6.8 oz (2.423 lb)

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by a member from D. See "Data change" for further contributors.
