Satmeter MSK 12 BN 208249
Kathrein; Rosenheim
- Country
- Germany
- Manufacturer / Brand
- Kathrein; Rosenheim
- Year
- 1994 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 259851
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Radio Frequency Amplification only
- Wave bands
- SAT-IF
- Power type and voltage
- Storage and/or dry batteries / 10 x 1,2 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Satmeter MSK 12 BN 208249 - Kathrein; Rosenheim
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 150 x 56 x 120 mm / 5.9 x 2.2 x 4.7 inch
- Notes
-
Satmeter mit analoger Anzeige 48-98 dBµV, 900-2050 MHz,
akustischer Signalton zum Ausrichten,
Anzeige von Signalpegel, Spannung, Strom, Akkuladezustand,
Speisung: 10 NiCad Batterien.
- Net weight (2.2 lb = 1 kg)
- 0.350 kg / 0 lb 12.3 oz (0.771 lb)
- Mentioned in
- -- Original prospect or advert
- Author
- Model page created by a member from D. See "Data change" for further contributors.
