• Country
• Germany

• Manufacturer / Brand
• Kathrein; Rosenheim

• Year
• 1995 ??

• Category
• Antenna (Aerial) or Coupler

• Radiomuseum.org ID
• 261372

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• SAT-IF

• Power type and voltage
• Powered by external power supply or a main unit. / DC 12-18 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Umschaltmatrize EXR 12 BN 273323 - Kathrein; Rosenheim

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 88.5 x 75 x 30 mm / 3.5 x 3 x 1.2 inch

• Notes

• Umschaltmatrize
  zum Zusammenschalten zweier LNC auf 1 Receiver,
  950-2050MHz, die Umschaltung erfolgt durch 22kHz Steuersignal,
  die Stromversorgung wird aus der LNC-Speisung entnommen.

• Net weight (2.2 lb = 1 kg)
• 0.2 kg / 0 lb 7 oz (0.441 lb)

• Mentioned in
• -- Original prospect or advert
