Powered Subwoofer PSW1000.2

KEF Electronics; Tovil, Maidstone, Kent

Data
Forum
Pictures
Collections

  • Year
  • 2002
  • Category
  • Loudspeaker, headphone or earphone
  • Radiomuseum.org ID
  • 302851

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • - without
  • Details
  • Loudspeaker + integr.Amplifier
  • Power type and voltage
  • Alternating Current supply (AC) / 115; 230 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
  • Power out
  • 100 W (max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Powered Subwoofer PSW1000.2 - KEF Electronics; Tovil,
  • Shape
  • Console with any shape - in general
  • Dimensions (WHD)
  • 320 x 360 x 320 mm / 12.6 x 14.2 x 12.6 inch
  • Notes

  • An active subwoofer in a Silver, Maple, Dark Apple or Black cabinet, designed to complement the KHT Series of home theatre loudspeakers.

    Specification
    System type: Active subwoofer
    Enclosure type: Closed box
    Dimensions (H x W x D): 360 x 320 x 320mm (14.2 x 12.6 x 12.6 inches)
    Weight: 13.5kg (29.7 lbs)
    Drive Unit: 200mm (8”) long throw
    Amplifier: 100W
    Frequency response: 38Hz to 180Hz +/-3.0dB
    Maximum output: 106dB

    Regolazioni input level/crossover frequency/phase adjust - commutatori ground in/out - music/cinema - slope 12 db/24 db - power auto/manual - high pass out L/R - power consumption 150 watt - led accensione - protezione termica

    Made in China.

  • Net weight (2.2 lb = 1 kg)
  • 13.5 kg / 29 lb 11.8 oz (29.736 lb)
  • Mentioned in
  • - - Manufacturers Literature
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
