Digital Multimeter 169 DMM

• Country
• United States of America (USA)

• Manufacturer / Brand
• Keithley Instruments Inc.; Cleveland (OH)

• Year
• 1979

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 129511

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 3

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / C: 6 × 1.5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Digital Multimeter 169 DMM - Keithley Instruments Inc.;

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 240 x 85 x 270 mm / 9.4 x 3.3 x 10.6 inch

• Notes
• The Keithley 169 Digital Multimeter has five functions: DCV (200 mV to 1000 V), DCA (200 µA to 2000 mA), ACV (200 mV to 1000 V), ACA (200 µA to 2000 mA), and Ohms (200-ohms to 20 Mohms), Input protected, auto polarity, auto-zeroing, non-rechargeable batteries.

• Net weight (2.2 lb = 1 kg)
• 1.3 kg / 2 lb 13.8 oz (2.863 lb)

• Price in first year of sale
• 535.00 $

• Literature/Schematics (1)
• Funkschau (23/1979, S. 1352)

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.

• Other Models

• Here you find 38 models, 33 with images and 16 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
