Digital Multimeter Autoranging DMM 168

Keithley Instruments Inc.; Cleveland (OH)

Data
Forum
Pictures
Collections

  • Year
  • 1974
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 129852

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Line / Batteries (any type) / 117; 234 / ? Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Digital Multimeter Autoranging DMM 168 - Keithley Instruments Inc.;
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 240 x 83 x 270 mm / 9.4 x 3.3 x 10.6 inch
  • Notes

  • The Keithley 168 is a verstile 4-digit autoranging digital multimeter useful for measurement of AC/DC voltage, AC/DC current and resistance.

    Voltage measurements can be made from +/- .0001 volt to +/- 1000 volt dc or .0001 volt to 500 volt ac.

    Current measurements can be made from .0001 milliampere to 1 ampere, ac and dc in two spans.

    Resistance measurements can be made from 0.1 ohm to 20 megohms in two overlapping spans.

    Range and polarity is automatically selected. In addition to the display of digits, the 168 indicates decimal point, function (AC or DC) and measurement unit.  Racel Da

    This Unit was also available from Rohde & Schwarz as Model MM635, and as Model 4003 from Racal Dana.



  • Net weight (2.2 lb = 1 kg)
  • 0.4 kg / 0 lb 14.1 oz (0.881 lb)
  • Author
  • Model page created by Karlheinz Fischer. See "Data change" for further contributors.
