35-K63 Ch= 35-K
Kelvinator; Keswick, South Australia
- Country
- Australia
- Manufacturer / Brand
- Kelvinator; Keswick, South Australia
- Year
- 1957
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 291268
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superhet with RF-stage; ZF/IF 457.5 kHz
- Wave bands
- Broadcast and Short Wave (SW).
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: 35-K63 Ch= 35-K - Kelvinator; Keswick, South
- Shape
- Tablemodel, Box - most often with Lid (NOT slant panel).
- Dimensions (WHD)
- 19.75 x 8.75 x 15 inch / 502 x 222 x 381 mm
- Notes
-
Rebadged HMV Nippergram 35-63 with a BSR UA8 changer.
Case colours in Maroon, Maroon/Beige & Blue/Green.
- Net weight (2.2 lb = 1 kg)
- 29 lb 0 oz (29 lb) / 13.166 kg
- Price in first year of sale
- 68.25 AUS £
- Literature/Schematics (1)
- - - Manufacturers Literature (Kelvinator Radio Service Manual for Type 35-K Chassis.)
- Literature/Schematics (2)
- J.R. Publications Radio Service Handbook (R.V. Series Vol. 1, Page H75.)
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
