- Country
- Australia
- Manufacturer / Brand
- Kelvinator; Keswick, South Australia
- Year
- 1957
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 290438
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 45.5 kHz
- Wave bands
- Broadcast and Short Wave (SW).
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 200-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 35K-34 - Kelvinator; Keswick, South
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 21.25 x 26.25 x 17.25 inch / 540 x 667 x 438 mm
- Notes
-
Rebadged version of HMV model 35-34.
Dual-Wave 4-speed automatic radiogram.
Cabinet finishes available in Walnut, Maple & Rosewood.
- Net weight (2.2 lb = 1 kg)
- 38 lb 8 oz (38.5 lb) / 17.479 kg
- Price in first year of sale
- 75.60 AUS £
- Literature/Schematics (1)
- J.R. Publications Radio Service Handbook (R.V. Series Vol. 1, 1963, Page H75.)
- Author
- Model page created by Martin Kent. See "Data change" for further contributors.
