AM-FM Stereo Receiver KR-4770

Kenwood, Trio-Kenwood Inc.; Komagane

Data
Forum
Pictures
Collections

  • Year
  • 1977
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 359228
    • alternative name: Trio Corp.
    • Brand: Jennen

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 50-60Hz, 120; 220; 240 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 80 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: AM-FM Stereo Receiver KR-4770 - Kenwood, Trio-Kenwood Inc.;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 470 x 150 x 394 mm / 18.5 x 5.9 x 15.5 inch
  • Notes

  • Bauähnlich mit dem KR-4070. Diesen gab es auch als KR-4070L mit zusätzlicher Langwelle.
    Den KR-4770 gab es nur mit AM/FM.

  • Net weight (2.2 lb = 1 kg)
  • 10.4 kg / 22 lb 14.5 oz (22.907 lb)
  • Mentioned in
  • - - Manufacturers Literature (Kenwood Katalog 1977/78)
  • Author
  • Model page created by Peter Liska. See "Data change" for further contributors.
