Meridian {Меридиан} RP-309 {РП-309}
Radiopribor n. S.P. Korolyov; Kiev
- Country
- Soviet Union
- Manufacturer / Brand
- Radiopribor n. S.P. Korolyov; Kiev
- Year
- 1992 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 232736
- Number of Transistors
- 2
- Semiconductors
- К174ХА10 КХА060 КТ313 unknown_tr
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Dry Batteries / 3 x AA 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.5 cm = 1.8 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Meridian {Меридиан} RP-309 {РП-309} - Radiopribor n. S.P. Korolyov;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 77 x 150 x 27 mm / 3 x 5.9 x 1.1 inch
- Notes
-
AM (MW): 525 - 1607 kHz
FM (VHF): OIRT 65 - 74 MHzSimilar model with AM (LW) and FM (VHF): Meridian RP-310.
- Net weight (2.2 lb = 1 kg)
- 0.240 kg / 0 lb 8.5 oz (0.529 lb)
- Author
- Model page created by Bernhard Nagel. See "Data change" for further contributors.
