OM Radio
King's Radio
- Country
- Italy
- Manufacturer / Brand
- King's Radio
- Year
- 1962 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 306912
- Number of Transistors
- 6
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / PP3: 1 x 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
- Power out
- 0.15 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: OM Radio - King's Radio
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 120 x 70 x 35 mm / 4.7 x 2.8 x 1.4 inch
- Notes
-
controllo volume - custodia in similpelle con maniglia di trasporto - antenna interna in ferrite - frequency range: 525 - 1605 kHz.
- Net weight (2.2 lb = 1 kg)
- 0.380 kg / 0 lb 13.4 oz (0.837 lb)
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
