Moderator 100-150

• Country
• Germany

• Manufacturer / Brand
• Kirksaeter, Düsseldorf

• Year
• 1980 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 172891

• • Brand: Audioson

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• FM Broadcast Band Only

• Power type and voltage
• Alternating Current supply (AC) / 110/220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 200 W (unknown quality)

• Material
• Various materials

• from Radiomuseum.org
• Model: Moderator 100-150 - Kirksaeter, Düsseldorf

• Shape
• Book-shelf unit.

• Author
• Model page created by Eberhard Franzke. See "Data change" for further contributors.

• Other Models

• Here you find 16 models, 16 with images and 5 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
