• Country
• Spain

• Manufacturer / Brand
• Klarmax-Radio; Asencio Quirant Gonzálvez; Elche

• Year
• 1955 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 280919

• Number of Tubes
• 5

• Valves / Tubes
• UCH81 UF41 UBC41 UL84 UY85

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• Broadcast, Short Wave(s) and Police.

• Power type and voltage
• AC/DC-set / 125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Power out
• 3 W (max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Desconocida-2 Unknown - Klarmax-Radio; Asencio Quirant

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 350 x 250 x 130 mm / 13.8 x 9.8 x 5.1 inch

• Notes

• Altavoz de 4 ohms.

• Net weight (2.2 lb = 1 kg)
• 2.6 kg / 5 lb 11.6 oz (5.727 lb)

• Author
• Model page created by Alberto Sanna-Alonso. See "Data change" for further contributors.
