Desconocida-5 Unknown
Klarmax-Radio; Asencio Quirant Gonzálvez; Elche
- Country
- Spain
- Manufacturer / Brand
- Klarmax-Radio; Asencio Quirant Gonzálvez; Elche
- Year
- 1955/1956 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 349769
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- 125; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Desconocida-5 Unknown - Klarmax-Radio; Asencio Quirant
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 355 x 250 x 185 mm / 14 x 9.8 x 7.3 inch
- Author
- Model page created by Victor Boj Cabistañ. See "Data change" for further contributors.
- Other Models
-
Here you find 32 models, 23 with images and 9 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Klarmax-Radio; Asencio Quirant Gonzálvez; Elche
