- Country
- Spain
- Manufacturer / Brand
- Klarmax-Radio; Asencio Quirant Gonzálvez; Elche
- Year
- 1962 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 336989
- Number of Tubes
- 3
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast, Short Wave(s) and Police.
- Power type and voltage
- Alternating Current supply (AC) / 125; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: KL-200 - Klarmax-Radio; Asencio Quirant
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 260 x 190 x 150 mm / 10.2 x 7.5 x 5.9 inch
- Notes
-
Altavoz elíptico de 3 x 6 pulgadas.
Alimentado por autotransformador, chasis no aislado de la red.
- Net weight (2.2 lb = 1 kg)
- 3.020 kg / 6 lb 10.4 oz (6.652 lb)
- Author
- Model page created by Carlos Saavedra. See "Data change" for further contributors.
