• Year
  • 1982 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 128066

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • FM Broadcast Band Only
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Line / Storage batteries (perhaps also batteries) / 220; 24 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 80 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Telewatt ELA-Center EZ 60 - Klein & Hummel; Stuttgart-
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 470 x 100 x 320 mm / 18.5 x 3.9 x 12.6 inch
  • Notes
  • UKW-Teil mit 7 Festsendertasten, integriertes Cassetten-Abspielgerät, vier schaltbare 100-V-Ausgänge, Lautsprecherausgänge programmierbar, Vorrangschaltung, Pflichtruf-Schaltung.
  • Net weight (2.2 lb = 1 kg)
  • 10.2 kg / 22 lb 7.5 oz (22.467 lb)
  • Literature/Schematics (1)
  • - - Manufacturers Literature (K+H, Produkt-Katalog)
  • Author
  • Model page created by Karlheinz Fischer. See "Data change" for further contributors.
