• Country
• Germany

• Manufacturer / Brand
• Klingenthaler Harmonikawerke, VEB; Klingenthal (Sachsen) (Vermona)

• Year
• 1982–1988

• Category
• Audio Amplifier or -mixer

• Radiomuseum.org ID
• 107546

• • alternative name: Musikelektronik Klingenthal (VEB) (Ostd.)

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• SC238 SC237 SC237 SF118 SF128 KD606 SF118 KD606

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 25 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Regent 310 - Klingenthaler Harmonikawerke,

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 470 x 345 x 330 mm / 18.5 x 13.6 x 13 inch

• Notes

• Aktiver Monitor 25/40 W, Breitbandlautsprecher; 1 Eingang, 1 Steuerausgang 0 dB 775 mV.

  Vorgestellt zur Leipziger Herbstmesse 1982.

• Net weight (2.2 lb = 1 kg)
• 13 kg / 28 lb 10.1 oz (28.634 lb)

• Price in first year of sale
• 348.00 DM

• Mentioned in
• -- Original prospect or advert (radio fernsehen elektronik 1982; H.12)

• Literature/Schematics (1)
• Conrad-Katalog 1988, Seite 242

• Author
• Model page created by Wolfgang Lill. See "Data change" for further contributors.
