CRT Regenerator TR-450

• Country
• Germany

• Manufacturer / Brand
• König Electronic GmbH; Reichelsheim

• Year
• 1985 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 250518

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 4

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: CRT Regenerator TR-450 - König Electronic GmbH;

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 165 x 100 x 250 mm / 6.5 x 3.9 x 9.8 inch

• Notes

• CRT Regenerator TR-450, Heizung 1,5/6,3/12 V, s/w und Farbbildröhren,
  25 und 50 mA, 1 und 5 µA schaltbar.

  Siehe auch das ähnliche Modell Promax RT-501B.

• Net weight (2.2 lb = 1 kg)
• 2.3 kg / 5 lb 1.1 oz (5.066 lb)

• Author
• Model page created by Karlheinz Fischer. See "Data change" for further contributors.
