• Country
• Spain

• Manufacturer / Brand
• Kolster Iberica, S.A. ; Barcelona

• Year
• 1976 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 323173

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 21

• Semiconductors
• SC109 SC109 SC109 SC109 SC109 MC150 AD161 AD162 SC108 SC108 AC188 AC188 AC188 BZY87 BZY87 OA91 OA91 OA91 AA135 AA135 AA135

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Powered by external power supply or a main unit. / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 4 W (6 W max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: Playsonic Car Stereo 8 Track - Kolster Iberica, S.A. ;

• Shape
• Chassis only or for «building in»

• Notes

• Reproductor de cassettes de ocho pistas para coche.
  Admite una tensión de alimentación entre 10-16 v.
  Distorsión armónica menor 1,5% a 4 W.
  Banda pasante entre 50Hz y 10kHz.
  Motor sin escobillas con autoregulación electróica.

  Lista de transistores para un solo canal de audio.

• Mentioned in
• Esquemario de Magnetófonos y cassettes IV 1977

• Author
• Model page created by Toni Gutiérrez García. See "Data change" for further contributors.
