• Country
• Great Britain (UK)

• Manufacturer / Brand
• Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB

• Year
• 1937

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 316539

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 15D1 9D2 10D1 7D6 1D5_rectifier

• Main principle
• Superheterodyne (common); ZF/IF 464 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• AC/DC-set / 195-270 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Power out
• 3 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: KB 592 - Kolster Brandes Ltd. KB, K.B.,

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Notes

• AC/DC version of KB 590

• Author
• Model page created by Mike Edwards † 25.10.21. See "Data change" for further contributors.
