Bench KH2023

Kompernass Handels GmbH; Bochum

Data
Forum
Pictures
Collections

  • Year
  • 2003
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 299114

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Batteries / addl. power jack / AA: 4 x 1.5 / 6 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Bench KH2023 - Kompernass Handels GmbH;
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 180 x 120 x 45 mm / 7.1 x 4.7 x 1.8 inch
  • Notes

  • – Electronic digital radio receiver
    – Power supply: 6.0V DC (Direct Current) from batteries (4 x AA, LR6 1.5V, not supplied) or from an external adapter 6.0-7.5V AC
    – Precision quartz operation
    – User-friendly operation using interactive LCD display
    – Current time and day of the week display
    – 24 hour mode display
    – Integrated calendar with automatic year switching from 1950 to 2049
    – World time display for 24 cities (see accompanying list for codes)
    – Remaining daylight display for local and world time, individually programmable.
    – Programmable time, date and world time displays.
    – Two independent alarm settings, e.g. for weekday and weekend alarm wake-up times
    – Select between radio or tone alarms.
    – Sleep Timer for up to 90 minutes.
    – Radio with 40 preset memories (10 memory presets per band)
    – Station search buttons, automatic or manual, forwards or backwards
    – Memory search
    – Weak battery display
    – Button lock feature to prevent unintentional button actuation.

    The receiver KH2023 was also sold under the brand name Tronic.



  • Net weight (2.2 lb = 1 kg)
  • 0.425 kg / 0 lb 15 oz (0.936 lb)
  • Mentioned in
  • - - Manufacturers Literature
  • Author
  • Model page created by Sándor Perneky. See "Data change" for further contributors.
