MT158

Körting-Radio; Leipzig, später Grassau

Data

Forum

Pictures

Collections

Country
Germany

Manufacturer / Brand
Körting-Radio; Leipzig, später Grassau

Year
1960 ?

Category
Sound/Video Recorder and/or Player

Radiomuseum.org ID
131745

- alternative name: Dietz & Ritter GmbH, Dr.

Schematics

MT158; Körting-Radio; (ID = 460864) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642480) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642481) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642482) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642483) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642484) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642485) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642486) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642487) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642488) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642489) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642490) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642491) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642492) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642493) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642494) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642495) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642496) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2643008) R-Player — Körting-Radio; MT158 (3)

MT158; Körting-Radio; (ID = 2642479) R-Player — Körting-Radio; MT158 (2)
Bild aus dem Service Manual

MT158; Körting-Radio; (ID = 460868) R-Player — Körting-Radio; MT158 (2)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
6

Valves / Tubes
ECC85 ECC85 EL95 EL95 EAM86 EL95

Number of Transistors
2

Semiconductors
OC44 OC44 B250C75 E25C5 E25C5

Main principle
Export model

Wave bands
- without

Details
Tape Recorder

Power type and voltage
Alternating Current supply (AC) / 60Hz, 117 Volt

Power out
2 W (unknown quality)

Material
Leather / canvas / plastic - over other material

from Radiomuseum.org
Model: MT158 - Körting-Radio; Leipzig, später

Shape
Tablemodel, with any shape - general.

Notes
Stereo Magnettongerät MT158 mit Vielfach-Überspieltechnik. USA-Exportmodell für 60 Hz und 117 V Netzspannung.

Siehe auch Körting MT157 für 50 Hz und Netzspannungsbereich 110-250 V.

Literature/Schematics (1)
Funk-Technik (FT) (17/1960, S. 609 - 611 / Beschreibung, Daten, Schema)

Author
Model page created by Egon Strampe. See "Data change" for further contributors.

Other Models
Here you find 815 models, 667 with images and 471 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Körting-Radio; Leipzig, später Grassau

Collections | Museums | Literature

Literature

The model is documented in the following literature.

Funk-Technik (FT)
