• Country
• Germany

• Manufacturer / Brand
• Körting-Radio; Leipzig, später Grassau

• Year
• 1933 ?

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 353485

• • alternative name: Dietz & Ritter GmbH, Dr.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors

• Semiconductors
• Tr.Gl.=Metal-rectif.

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 120; 220 V or 110; 125; 150; 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 18 cm = 7.1 inch

• Power out
• 2 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Excello Domette WT - Körting-Radio; Leipzig, später

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 350 x 340 x 180 mm / 13.8 x 13.4 x 7.1 inch

• Notes

• Körting Domette WT, Lautsprecher für Wechselstrom im Edelholzgehäuse, bis 2 W belastbar.
  Mit Trockengleichrichter.
  Eingebauter Universaltransformator für alle gebräuchlichen Endröhren.

• Net weight (2.2 lb = 1 kg)
• 7.2 kg / 15 lb 13.7 oz (15.859 lb)

• Price in first year of sale
• 85.00 RM

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by a member from D. See "Data change" for further contributors.
