FM-Stereo Adapter Multiplex-Decoder 22914
Körting-Radio; Leipzig, später Grassau
- Country
- Germany
- Manufacturer / Brand
- Körting-Radio; Leipzig, später Grassau
- Year
- 1961
- Category
- Radio module post 1925 (not a part, not a key)
- Radiomuseum.org ID
- 163904
-
- alternative name: Dietz & Ritter GmbH, Dr.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 2
- Wave bands
- - without
- Power type and voltage
- Powered by external power supply or a main unit. / AC 6,3 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: FM-Stereo Adapter Multiplex-Decoder 22914 - Körting-Radio; Leipzig, später
- Shape
- Chassis only or for «building in»
- Source of data
- -- Schematic
- Mentioned in
- Funk-Technik (FT) (24/1961, S. 864)
- Literature/Schematics (1)
- Funkschau (2/1962, S. 33)
- Author
- Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
