TR621 Ch= 26 021
Körting-Radio; Leipzig, später Grassau
- Country
- Germany
- Manufacturer / Brand
- Körting-Radio; Leipzig, später Grassau
- Year
- 1964 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 353722
-
- alternative name: Dietz & Ritter GmbH, Dr.
- Number of Transistors
- 7
- Semiconductors
- AF124 AF124 unknown_tr
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 3R12: 2 x 4,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Various materials
- from Radiomuseum.org
- Model: TR621 Ch= 26 021 - Körting-Radio; Leipzig, später
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 280 x 85 x 170 mm / 11 x 3.3 x 6.7 inch
- Notes
-
Anschluss für Aussenantenne.
- Author
- Model page created by Bruce Cohen. See "Data change" for further contributors.
