Ultramar 37 SB8360W normal

Körting-Radio; Leipzig, später Grassau

Data

Forum

Pictures

Collections

Country
Germany

Manufacturer / Brand
Körting-Radio; Leipzig, später Grassau

Year
1936/1937

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
2440

- alternative name: Dietz & Ritter GmbH, Dr.

Schematics

Ultramar 37 SB8360W; Körting-Radio; (ID = 72936) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 72937) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 72938) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 72939) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 72944) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 72940) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 72941) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 72942) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 72943) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 4793) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 1468885) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 1468886) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 2555818) Radio — Körting-Radio; Ultramar 37 SB8360W (3)

Ultramar 37 SB8360W; Körting-Radio; (ID = 12861) Radio — Körting-Radio; Ultramar 37 SB8360W (1)

Ultramar 37 SB8360W; Körting-Radio; (ID = 190359) Radio — Körting-Radio; Ultramar 37 SB8360W (2)

Ultramar 37 SB8360W; Körting-Radio; (ID = 355813) Radio — Körting-Radio; Ultramar 37 SB8360W (1)

Ultramar 37 SB8360W; Körting-Radio; (ID = 355817) Radio — Körting-Radio; Ultramar 37 SB8360W (1)
Unteransicht Chassis re

Ultramar 37 SB8360W; Körting-Radio; (ID = 1343386) Radio — Körting-Radio; Ultramar 37 SB8360W (1)
aus LL. Gerät nicht mehr in meinem Besitz.

Ultramar 37 SB8360W; Körting-Radio; (ID = 1343387) Radio — Körting-Radio; Ultramar 37 SB8360W (1)
aus LL. Gerät nicht mehr in meinem Besitz.

Ultramar 37 SB8360W; Körting-Radio; (ID = 1343388) Radio — Körting-Radio; Ultramar 37 SB8360W (1)
aus LL. Gerät nicht mehr in meinem Besitz.

Ultramar 37 SB8360W; Körting-Radio; (ID = 1343389) Radio — Körting-Radio; Ultramar 37 SB8360W (1)
aus LL. Gerät nicht mehr in meinem Besitz.

Ultramar 37 SB8360W; Körting-Radio; (ID = 1773167) Radio — Körting-Radio; Ultramar 37 SB8360W (1)

Ultramar 37 SB8360W; Körting-Radio; (ID = 1773169) Radio — Körting-Radio; Ultramar 37 SB8360W (1)

Ultramar 37 SB8360W; Körting-Radio; (ID = 1773171) Radio — Körting-Radio; Ultramar 37 SB8360W (1)

Ultramar 37 SB8360W; Körting-Radio; (ID = 1773172) Radio — Körting-Radio; Ultramar 37 SB8360W (1)

Ultramar 37 SB8360W; Körting-Radio; (ID = 1773173) Radio — Körting-Radio; Ultramar 37 SB8360W (1)

Ultramar 37 SB8360W; Körting-Radio; (ID = 1773174) Radio — Körting-Radio; Ultramar 37 SB8360W (1)

Ultramar 37 SB8360W; Körting-Radio; (ID = 1773218) Radio — Körting-Radio; Ultramar 37 SB8360W (1)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
11

Valves / Tubes
AF3 AK2 AF3 AF3 ABC1 AC2 AC2 AD1 AD1 RGN1064 RGN1064

Main principle
Superhet with RF-stage; ZF/IF 468 kHz

Tuned circuits
9 AM circuit(s)

Wave bands
Broadcast, Long Wave and 2 x Short Wave.

Power type and voltage
Alternating Current supply (AC) / 110-240 Volt

Loudspeaker
2 Loudspeakers

Material
Wooden case

from Radiomuseum.org
Model: Ultramar 37 SB8360W [normal] - Körting-Radio; Leipzig, später

Shape
Tablemodel, low profile (big size).

Dimensions (WHD)
575 x 565 x 335 mm / 22.6 x 22.2 x 13.2 inch

Notes

Net weight (2.2 lb = 1 kg)
34 kg / 74 lb 14.2 oz (74.89 lb)

Price in first year of sale
640.00 RM

Source of data
HandB.d.d.Rundfunk-Handels 1936/37 / Radiokatalog Band 1, Ernst Erb

Circuit diagram reference
Lange+Schenk+FS-Röhrenbestückung

Mentioned in
Funkgeschichte der GFGF (9286)
