Elektronik-Junior
Kosmos, Franckh´sche Verlagshandlung
- Country
- Germany
- Manufacturer / Brand
- Kosmos, Franckh´sche Verlagshandlung
- Year
- 1980/1981
- Category
- Kit (Parts plus instruction) or building instructions only
- Radiomuseum.org ID
- 86376
Heft titelseite
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / 3 x 1,5 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Various materials
- from Radiomuseum.org
- Model: Elektronik-Junior - Kosmos, Franckh´sche
- Notes
- Interessante Experimente vom einfachen Schaltkreis bis zum Mittelwellenradio.
- Source of data
- -- Original prospect or advert / Radiokatalog Band 2, Ernst Erb
- Author
- Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
