- Country
- Australia
- Manufacturer / Brand
- Kriesler Radio Company; Newtown (Sydney)
- Year
- 1953
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 193578
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 220; 240; 260 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 11-34 - Kriesler Radio Company;
- Shape
- Console with any shape - in general
- Notes
-
Radiogram with 3-speed record changer.
Cabinet finishes available in Maple or Coachwood.
- Price in first year of sale
- 114.45 AUS £
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. XII
- Literature/Schematics (1)
- - - Manufacturers Literature (Kriesler Technical Service Instructions.)
- Literature/Schematics (2)
- Australian Official Radio Service Manual AORSM (Volume 12, 1954, Page 223.)
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
