Davoli A6 DTE534
Krundaal Davoli; Parma
- Country
- Italy
- Manufacturer / Brand
- Krundaal Davoli; Parma
- Year
- 1960 ??
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 296359
- Number of Tubes
- 2
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Guitar Amplifier
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 145; 160; 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
- Power out
- 6 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Davoli A6 DTE534 - Krundaal Davoli; Parma
- Shape
- Miscellaneous shapes - described under notes.
- Dimensions (WHD)
- 485 x 360 x 200 mm / 19.1 x 14.2 x 7.9 inch
- Notes
-
Amplificatore per strumenti musicali elettrici.
Due ingressi jack con diverse sensibilità.
Controllo di volume e controllo di tono con interruttore di accensione.
Funzione di tremolo a due velocità (lento e veloce) disattivabile con comando a distanza.
- Net weight (2.2 lb = 1 kg)
- 5.9 kg / 12 lb 15.9 oz (12.996 lb)
- Author
- Model page created by Gianluigi Miazzi. See "Data change" for further contributors.
