Palma Ch= 666
Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
- Country
- Germany
- Manufacturer / Brand
- Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
- Year
- 1967/1968
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 27083
-
- alternative name: Imperial Kuba
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Number of Transistors
- 4
- Semiconductors
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 6 AM circuit(s) 12 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 4 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Palma Ch= 666 - Kuba Kuba-Imperial, G.
- Shape
- Console with Push Buttons.
- Dimensions (WHD)
- 1180 x 760 x 400 mm / 46.5 x 29.9 x 15.7 inch
- Notes
- Rundfunk-Chassis = 666-Stereo;
Phono-Chassis = Philips SW88
- Net weight (2.2 lb = 1 kg)
- 41 kg / 90 lb 4.9 oz (90.308 lb)
- External source of data
- erb
- Source of data
- Handbuch VDRG 1967/1968 / Radiokatalog Band 2, Ernst Erb
