Viceroy SSB Transmitter Mark III

K.W. Electronics Ltd.; Dartford

Data
Forum
Pictures
Collections

  • Year
  • 1962 ?
  • Category
  • Amateur Transmitter (only)
  • Radiomuseum.org ID
  • 221388

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 18
  • Main principle
  • Transmitter; ZF/IF 435 kHz
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Alternating Current supply (AC) / 200/ 230/ 250 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Viceroy SSB Transmitter Mark III - K.W. Electronics Ltd.;
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 54.5 x 27.8 x 41.2 mm / 2.1 x 1.1 x 1.6 inch
  • Notes

  • The K.W. Viceroy Mark III superceded the Mark II and added an additional crystal to the carrier oscillator to enable coverage of more of the 10m band in two ranges. The Mark III has a built-in power supply, with the function switch (Power / Tune / VW / VOX / MOX) on the front panel. Less often used controls were moved to the rear panel, and the microphone socket is on the front panel.

    Covers the 80m (3.5-4.0 MHz), 40m (7.0-7.3 MHz), 20m (14.0-14.5 MHz), 15m (21.0-21.5 MHz) and 10m (28.0-28.6 and 28.6-29.2 MHz) amateur bands in six ranges.

    Power output is 180 W PEP input on SSB, 150 W on C.W. and 90 W AM.

  • Net weight (2.2 lb = 1 kg)
  • 32 kg / 70 lb 7.8 oz (70.485 lb)
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by Rudolf Müller. See "Data change" for further contributors.
