• Country
• Japan

• Manufacturer / Brand
• Kyoritsu Electrical Instrument Works Ltd. (KEW); Tokyo

• Year
• 1982 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 223816

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Dry Batteries / 1,5 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Multimeter 1104 - Kyoritsu Electrical Instrument

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 133 x 37 x 90 mm / 5.2 x 1.5 x 3.5 inch

• Notes
• 10 Kohm/ V DC
  4,37 Kohm/V AC
  Pilas: 1 of 1,5 Volt AAA

• Author
• Model page created by Carlos A. Pieroni-García. See "Data change" for further contributors.
