• Country
• Argentina

• Manufacturer / Brand
• Laboratorios Douglas S.A.C.I.; Buenos Aires

• Year
• 1935 ??

• Category
• Kit (Parts plus instruction) or building instructions only

• Radiomuseum.org ID
• 190200

• • alternative name: Douglas Argentina

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 2A7 58 2A6 2A5 80

• Main principle
• ZF/IF 465 kHz; 2 AF stage(s)

• Tuned circuits
• 4 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 3.2 W (unknown quality)

• from Radiomuseum.org
• Model: 45C - Laboratorios Douglas S.A.C.I.;

• Notes
• Transformador de audio para carga de 1800 ohm.

• Author
• Model page created by Cristian Wolkenstein. See "Data change" for further contributors.
