Serie S 57-1 Circuito 1
Laboratorios Douglas S.A.C.I.; Buenos Aires
- Country
- Argentina
- Manufacturer / Brand
- Laboratorios Douglas S.A.C.I.; Buenos Aires
- Year
- 1950 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 306765
-
- alternative name: Douglas Argentina
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- from Radiomuseum.org
- Model: Serie S 57-1 [Circuito 1] - Laboratorios Douglas S.A.C.I.;
- Notes
-
Este receptor se vendía en forma de KIT.
- Author
- Model page created by Mario Batista. See "Data change" for further contributors.
