Comprobador de Válvulas PL-800-A (Tube Tester)
LME Laboratorio de Metrologia Electrónica; Barcelona
- Country
- Spain
- Manufacturer / Brand
- LME Laboratorio de Metrologia Electrónica; Barcelona
- Year
- 1963
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 171627
Foto del catálogo LME 1963
foto miliamperimetro panel dial
vista general frontal del panel de mandos.
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Comprobador de Válvulas PL-800-A - LME Laboratorio de Metrologia
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 370 x 270 x 180 mm / 14.6 x 10.6 x 7.1 inch
- Notes
- 16 zócalos (sockets).
- Net weight (2.2 lb = 1 kg)
- 7.5 kg / 16 lb 8.3 oz (16.52 lb)
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
