B-60

Lafayette Radio & TV Corp; New York (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1933/1934
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 45869
    • alternative name: Wholesale Radio

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 9
  • Main principle
  • Superhet with RF-stage; ZF/IF 175 kHz; 3 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Power type and voltage
  • Storage and/or dry batteries / 2 & 135 & 16.5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: B-60 - Lafayette Radio & TV Corp; New
  • Shape
  • Console, Lowboy (legs < 50 %).
  • Dimensions (WHD)
  • 25 x 42.5 x 13 inch / 635 x 1080 x 330 mm
  • Notes
  • Rider's volume 5-5 is listing the 10-tube-Battery "Super-Het" Lafayette B-60 with RF stage, which tunes with an increased wavelength rate from 530 to 1750 kc (165 - 565 m). The plan dates from August 1933. The B-60 has an AVC and an instrument tuning meter. One tube 30 is used as a diode as 2nd detector. The instrument is not given on Rider's plan. The chassis measures 13.125" x 10" (hight) x 9.125" and is cadmium plated. The console low boy is 6 legged. We do not count the 10AB ballast tube and see this as a 9-tube model with push-pull output.

    The model B-60 is listed at $ 95.00 but the Lafayette price is $ 52.50 without batteries. See details for the models of this catalog.
  • Price in first year of sale
  • 53.00 $
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 5 = ca. 1934 and before
