• Country
• United States of America (USA)

• Manufacturer / Brand
• Lafayette Radio & TV Corp; New York (NY)

• Year
• 1940

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 184056

• • alternative name: Wholesale Radio

• Number of Tubes
• 9

• Valves / Tubes
• 6SK7 6SA7 6SK7 1853 1853 6SJ7 6H6 6R7 80

• Main principle
• Superhet with RF-stage; 1 AF stage(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: Ch= FM-12 - Lafayette Radio & TV Corp; New

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 16.75 x 9 x 15 inch / 425 x 229 x 381 mm

• Notes
• THe chassis model FM-12 is used in the models FM-13 and FM-14. The power amplifier with rectifier is a separate unit not contained in the chassis FM-12. Tuning is aided by a tuning meter showing the signal strength. This model is completely different to the model FM-12 manufactured by Pilot Radio Corp..

  See details and summaries for the models of this Lafayette catalog no. 82, 1941 for radio season 1940/41.

• Price in first year of sale
• 70.00 $

• Mentioned in
• Lafayette Radio Catalog (catalog NO.82, page 22)

• Author
• Model page created by Felix Schaffhauser. See "Data change" for further contributors.
