- Country
- United States of America (USA)
- Manufacturer / Brand
- Lafayette Radio & TV Corp; New York (NY)
- Year
- 1931/1932
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 162313
-
- alternative name: Wholesale Radio
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 110 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: LT-6 - Lafayette Radio & TV Corp; New
- Shape
- Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
- Dimensions (WHD)
- 13.25 x 15 x 9.25 inch / 337 x 381 x 235 mm
- Notes
- The Lafayette LT-6 Superhet can have an incorporated Telechron Electric Clock - or be without.
This model is sold as mantel cabinet (cathedral type) with a Lafayette price $ 24.50 for the set without clock and less tubes - including tubes it is $ 29.85 and with RCA tubes $ 30.82. Including the Telechron Electric Clock it costs additional $ 5.00. See details or summaries about this catalog.
- Price in first year of sale
- 30.00 $
- Literature/Schematics (1)
- Lafayette Radio Catalog (Lafayette 10th Anniversary catalog 1932, page 25.)
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
