Solid State Receiver LR 200

Lafayette Radio & TV Corp; New York (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1973
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 339511
    • alternative name: Wholesale Radio

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 29
  • Main principle
  • Superheterodyne (common); ZF/IF 455/10700 kHz
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 50-60 Hz: 105 to 120 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 45 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Solid State Receiver LR 200 - Lafayette Radio & TV Corp; New
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 14.5 x 4.5 x 10.5 inch / 368 x 114 x 267 mm
  • Notes

  • Solid State Receiver LR 200 has the following features:

    • AM (MW) and FM stereo/mono with output amplifiers for external speakers or headphones.
    • Built-in circuit for 4-Dimensional Stereo.
    • Power output max is 22.5 + 22.5 W RMS with 8Ω speakers.
    • Total harmonic distortion of 1% or less at rated output.
    • Input/output for tape, input for AUX, and input for ceramic or magnetic phono.
    • Headphones jack.

    29 Transistors, 3 ICs and 2 Diodes, listed one per type.

  • Price in first year of sale
  • 174.95 USD
  • Mentioned in
  • -- Schematic (Courtesy of Elektrotanya free schematic website)
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
