• Country
• United States of America (USA)

• Manufacturer / Brand
• Lang Radio Corp.; Brooklyn, NY

• Year
• 1925 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 186271

• Number of Tubes
• 6

• Valves / Tubes
• UX201A UX201A UX201A UX201A UX201A UX201A

• Main principle
• TRF without regeneration

• Tuned circuits
• 3 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Direct Current supply (DC) / 110 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Wooden case

• from Radiomuseum.org
• Model: Electric Six - Lang Radio Corp.; Brooklyn, NY

• Shape
• Tablemodel, slant panel.

• Dimensions (WHD)
• 475 x 225 x 225 mm / 18.7 x 8.9 x 8.9 inch

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by Hugo Sneyers. See "Data change" for further contributors.
