• Country
• United States of America (USA)

• Manufacturer / Brand
• Lansing, James B. (JBL), Los Angeles, CA

• Year
• 2002 ?

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 341134

• • Brand: JBL

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• 2 Loudspeakers

• Power out
• 120 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 2-Way Speaker System ATX-20 - Lansing, James B. JBL, Los

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 202 x 350 x 237 mm / 8 x 13.8 x 9.3 inch

• Notes

• 2-Way Speaker System Model JBL ATX-20

  Frequency Response: 70Hz to 20kHz

  Power Handling: 60 Watt / 120 Watt Peak

  Crossover : 4000Hz

  Impedance: 6Ω

  Sensitivity: 88dB

  Drivers:
  Bass: 1x 165mm cone (A0906A)
  Tweeter: 1x 10mm titanium dome (A0901A)
  Network:
  NATX-20

  Finish: Black Ash or Beach Vinyl Laminate with Dark Grey Grille

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)

• Price in first year of sale
• 149.00 EU

• Mentioned in
• -- Original prospect or advert

• Literature/Schematics (1)
• Owners Guide ATX Series, ATX20/30/40/60/10C/100S (230V), 2002, P/N 1111-ATXSERIES

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
